Brands |
N/A Vecoplan® |
Hopper Opening Length |
N/A 82 in |
Hopper Opening Width |
N/A 70 in |
Hopper Volume |
N/A 10.25 yd³ |
Rotor Diameter |
N/A 20 in |
Number of Cutters |
N/A 84 pieces |
Rotor Speed |
N/A 125 rpm |
Drive Motor Power |
N/A 150 hp |
Feed System (hp/Speed) |
N/A 10/2 |
Machine Weight |
N/A 18,000 to 22,000 lb |
Number of Phase |
N/A 3 |
Frequency |
N/A 60 Hz |
Riser Base Size |
N/A 24 in |
Standards |
N/A International Organization for Standardization (ISO 9001) |
Voltage |
N/A 460 V |
Options |
N/A Application Specific Programming Energy Saving HiTorc™ Drive Package High Speed Ram Optional Control Brands Optional Water Cooler Rotor Quick Disconnect and Quick Clean Screens |
Features |
N/A “Smart” Ram Programming 24 in Machine Base 24 in Riser Base Included 4-Way, Indexable Cutting Inserts Double Row Cutters Double Sidewall at Rotor Easy Access Screen Fully Hard-Faced Rotor Hardened Extended-Life Counter Knife Hardox Manganese-Alloy Sidewalls Hardox Screen Heavy-Duty Ram and Wiper Package ISO 9001 Manufactured Outboard Rotor Bearing Package PLC Control Panel Reinforced Floor, Ram, T. Arm, Wipers, Motor Mount Smart Ram Programming Package Touch Pad Monitoring and Control Tramp Metal Protection Wear Resistant Floor |
