Brands |
N/A Vecoplan® |
Hopper Opening Length |
N/A 48 in |
Hopper Opening Width |
N/A 42 in |
Hopper Volume |
N/A 2.9 yd³ |
Rotor Diameter |
N/A 10 in |
Number of Cutters |
N/A 27 |
Rotor Speed |
N/A 120 rpm |
Drive Motor Power |
N/A 30 hp |
Feed System (hp/Speed) |
N/A 3 to 5/2 |
Machine Weight |
N/A 5,700 lb |
Voltage |
N/A 460 V |
Number of Phase |
N/A 3 |
Frequency |
N/A 60 Hz |
Knife Gap |
N/A 0.015 in |
Cutter Size |
N/A 40 x 40 mm |
Standards |
N/A International Organization for Standardization (ISO 9001) |
Options |
N/A Abrasion Resistant Screens Control Integration Custom Hoppers Multiple Rotor Configurations Pneumatic Pick-Up Hoods Turn-Key Installation with Custom Conveyor Systems Engineering and Material Handling Equipment |
Features |
N/A 0.015 in Knife Gap 4-Way, Indexable Cutting Inserts Easy Access Screen Easy Accessibility Equity “Buyback” Guarantee Fluid “TurboCoupling” Heavy Outboard Spherical Roller Bearings High Output “Torsion Point” Cutting Rotor Hinged Protective Cylinder Covers ISO 9001 Manufactured Large Infeed Hopper Lifetime Limited Warranty on Cutting Rotor Low RPM / Low Noise Low Speed / High Torque Design Oversized Drivetrain PLC Control Panel Precision Hydraulic "Process Ram" Rugged Hydraulics Severe Duty Construction Stress-Free Frame, Robotically Welded Touch Pad Monitoring and Control Tramp Metal Protection |
