Brands |
N/A Vecoplan® |
Hopper Opening Length |
N/A 86 in |
Hopper Opening Width |
N/A 70 in |
Hopper Volume |
N/A 11 yd³ |
Rotor Diameter |
N/A 25 in |
Number of Cutters |
N/A 126 |
Rotor Speed |
N/A 145 rpm |
Drive Motor Power |
N/A 200 hp |
Feed System (hp/Speed) |
N/A 10/2 |
Machine Weight |
N/A 22,000 to 26,000 lb |
Voltage |
N/A 460 V |
Number of Phase |
N/A 3 |
Frequency |
N/A 60 Hz |
Available with |
N/A Airspring™ Counterknife (VAZ 1800-XL F) |
Cutter Size |
N/A 40 x 40 mm |
Standards |
N/A International Organization for Standardization (ISO 9001) |
Options |
N/A Application Specific Programming and Control Integration Complete Turn-Key Recycling and Reclamation Systems and Material Handling Products Installation Critical-Duty Drivetrain High Speed Ram Optional Control Brands Quick Disconnect and Quick Clean Screens Special Purpose Screens Wear Resistant Cutting Chamber |
Features |
N/A 0.015 in Knife Gap 4-Way, Indexable Cutting Inserts Easy Access Screen Easy Accessibility Equity “Buyback” Guarantee Fluid “TurboCoupling” Heavy Outboard Spherical Roller Bearings High Output “Torsion Point” Cutting Rotor Hinged Protective Cylinder Covers ISO 9001 Manufactured Large Infeed Hopper Lifetime Limited Warranty on Cutting Rotor Low RPM / Low Noise Low Speed / High Torque Design Oversized Drivetrain PLC Control Panel Precision Hydraulic "Process Ram" Rugged Hydraulics Severe Duty Construction Stress-Free Frame, Robotically Welded Touch Pad Monitoring and Control Tramp Metal Protection |
