Brands |
N/A Vecoplan® |
Hopper Opening Length |
N/A 78 in |
Hopper Opening Width |
N/A 78 in |
Rotor Diameter |
N/A 25 in |
Number of Cutters |
N/A 92 |
Rotor Speed |
N/A 120 rpm |
Drive Motor Power |
N/A 200 to 300 hp |
Feed System (hp/Speed) |
N/A 12.5/2 |
Machine Weight |
N/A 39,683 lb |
Voltage |
N/A 460 V |
Number of Phase |
N/A 3 |
Frequency |
N/A 60 Hz |
Nipper Cutter |
N/A 45 |
Standard Cutter Size |
N/A 40 x 40 |
Standards |
N/A International Organization for Standardization (ISO 9001) |
Options |
N/A Abrasion Resistant Screens Air Spring Counter Knife Control Integration Custom Hoppers Turn-Key Installation with Custom Conveyor Systems Engineering and Material Handling Equipment |
Features |
N/A “Flipper” Floating Counter Knife 0.015 in Knife Gap for Thin Materials Built-In Thermal Monitoring Controls for Rotor Critical Duty Drivetrain Diverter Plate Over Cutting Rotor Easy Access Screen Fluid “TurboCoupling” Heavy Oversized Outboard Spherical Roller Bearings Heavy Viscosity Fluids Hinged Protective Cylinder Covers ISO 9001 Manufactured Large Infeed Hopper Lifetime Limited Warranty on Cutting Rotor Low Speed / High Torque Design Passive Programming for Self-Feed Materials PLC Controls / Touch Pad Monitoring Precision Hydraulic "Process Ram" Reinforced Screens Rugged Hydraulics Special Composite 4-Way Indexable Cutting Inserts SureCut™ Cutting System Tramp Metal Protection Wear Resistant Siderails and Cutting Chamber |
