Brands |
N/A Vecoplan® |
Hopper Opening Length |
N/A 28 in |
Hopper Opening Width |
N/A 32 in |
Hopper Volume |
N/A 0.75 yd³ |
Rotor Diameter |
N/A 6.5 in |
Number of Cutters |
N/A 15 |
Rotor Speed |
N/A 280 rpm |
Drive Motor Power |
N/A 20 hp |
Feed System (hp/Speed) |
N/A 1.5 to 2/2 |
Machine Weight |
N/A 1,900 lb |
Voltage |
N/A 460 V |
Number of Phase |
N/A 3 |
Frequency |
N/A 60 Hz |
Cutter Size |
N/A 50 x 40 mm |
Standards |
N/A International Organization for Standardization (ISO 9001) |
Options |
N/A Abrasion Resistant Screens Control Integration Custom Hoppers Turn-Key Installation with Custom Conveyor Systems Engineering and Material Handling Equipment |
Features |
N/A “Starfeed” Rotating Counter Knife 4-Way, Indexable Cutting Inserts Easy Accessibility Equity “Buyback” Guarantee Heavy Outboard Spherical Roller Bearings Heavy-Duty Construction High Output “Torsion Point” Cutting Rotor ISO 9001 Manufactured Large Infeed Hopper Lifetime Limited Warranty on Cutting Rotor Low RPM / Low Noise Low Speed / High Torque Design Oversized Drivetrain PLC Control Panel Pneumatic Pickup Hood Included Stress-Free Frame, Robotically Welded Tramp Metal Protection |
